Pasowania ISO wg podstawowego wałka i otworu
Pasowania ISO - system wałka podstawowego (wg normy DIN 7155)
W systemie wałka podstawowego wszystkie wałki posiadają tolerancję h. W ten sposób największy wymiar wałka dochodzi do linii zerowej i jest równy wymiarowi nominalnemu. Najmnieszy wymiar wałka jest mniejszy od jego wymiaru nominalnego o tolerancję.
  |
|
Otwory - pole tolerancji |
Rodzaj pasowania* |
Wymiar nominalny od .... do ...... mmm |
||||||||||||||||||
|
1 3 |
3 6 |
6 10 |
10 14 |
14 18 |
18 24 |
24 30 |
30 40 |
40 50 |
50 65 |
65 80 |
80 100 |
100 120 |
120 140 |
140 160 |
160 180 |
180 200 |
200 225 |
225 250 |
||
| Odchyłki w ?m | ||||||||||||||||||||
|
wałek h5 |
0 -4 |
0 -5 |
0 -6 |
0 -8 |
0 -9 |
0 -11 |
0 -13 |
0 -15 |
0 -18 |
0 -20 |
||||||||||
| P 6 |
-6 -12 |
-9 -17 |
-12 -21 |
-15 -26 |
-18 -31 |
-21 -37 |
-26 -45 |
-30 -52 |
-36 -61 |
-40 -70 |
||||||||||
| N 6 |
-4 -10 |
-5 -13 |
-7 -16 |
-9 -20 |
-11 -24 |
-12 -28 |
-14 -33 |
-16 -38 |
-20 -45 |
-22 -51 |
||||||||||
| M 6 |
-2 -8 |
-1 -9 |
-3 -12 |
-4 -15 |
-4 -17 |
-4 -20 |
-5 -24 |
-6 -28 |
-8 -33 |
-8 -37 |
||||||||||
| J 6 |
+3 -4 |
+5 -3 |
+5 -4 |
+6 -5 |
+8 -5 |
+10 -6 |
+13 -6 |
+16 -6 |
+18 -7 |
+22 -7 |
||||||||||
| H 6 |
+6 0 |
+8 0 |
+9 0 |
+11 0 |
+13 0 |
+16 0 |
+19 0 |
+22 0 |
+25 0 |
+29 0 |
||||||||||
| wałek h6 |
0 -6 |
0 -8 |
0 -9 |
0 -11 |
0 -13 |
0 -16 |
0 -19 |
0 -22 |
0 -25 |
0 -29 |
||||||||||
| S 7 |
-14 -24 |
-15 -27 |
-17 -32 |
-21 -39 |
-27 -48 |
-34 -59 |
-42 -72 |
-48 -78 |
-58 -93 |
-66 -101 |
-77 -117 |
-85 -125 |
-93 -133 |
-105 -151 |
-113 -159 |
-123 -169 |
||||
| R 7 |
-10 -20 |
-11 -23 |
-13 -28 |
-16 -34 |
-20 -41 |
-25 -50 |
-30 -60 |
-32 -62 |
-38 -73 |
-41 -76 |
-48 -88 |
-50 -90 |
-53 -93 |
-60 -106 |
-63 -109 |
-67 -113 |
||||
| N 7 |
-4 -14 |
-4 -16 |
-4 -19 |
-5 -23 |
-7 -28 |
-8 -33 |
-9 -39 |
-10 -45 |
-12 -52 |
-14 -60 |
||||||||||
| M 7 |
-2 -12 |
0 -12 |
0 -15 |
0 -18 |
0 -21 |
0 -25 |
0 -30 |
0 -35 |
0 -40 |
0 -46 |
||||||||||
| K 7 |
+3 -6 |
+3 -6 |
+5 -10 |
+6 -12 |
+6 -15 |
+7 -18 |
+9 -21 |
+10 -25 |
+12 -28 |
+13 -33 |
||||||||||
| J 7 |
+3 -6 |
+6 -6 |
+8 -7 |
+10 -8 |
+12 -9 |
+14 -11 |
+18 -12 |
+22 -13 |
+26 -14 |
+30 -16 |
||||||||||
| H 7 | S |
+9 0 |
+12 0 |
+15 0 |
+18 0 |
+21 0 |
+25 0 |
+30 0 |
+35 0 |
+40 0 |
+46 0 |
|||||||||
| G 7 | S |
+12 +2 |
+16 +4 |
+20 +5 |
+24 +6 |
+28 +7 |
+34 +9 |
+40 +10 |
+47 +12 |
+54 +14 |
+61 +15 |
|||||||||
| F 7 |
+16 +6 |
+22 +10 |
+28 +13 |
+34 +16 |
+41 +20 |
+50 +25 |
+60 +30 |
+71 +36 |
+83 +43 |
+96 +50 |
||||||||||
| wałek h9 |
0 -25 |
0 -30 |
0 -36 |
0 -43 |
0 -52 |
0 -62 |
0 -74 |
0 -87 |
0 -100 |
0 -115 |
||||||||||
| H 8 | S |
+14 0 |
+18 0 |
+22 0 |
+27 0 |
+33 0 |
+39 0 |
+46 0 |
+54 0 |
+63 0 |
+72 0 |
|||||||||
| H 11 | S |
+60 0 |
+75 0 |
+90 0 |
+110 0 |
+130 0 |
+160 0 |
+190 0 |
+220 0 |
+250 0 |
+290 0 |
|||||||||
| F 8 | S |
+20 +6 |
+28 +10 |
+35 +13 |
+43 +16 |
+53 +20 |
+64 +25 |
+76 +30 |
+90 +36 |
+106 +43 |
+122 +50 |
|||||||||
| E 9 | S |
+39 +14 |
+50 +20 |
+61 +25 |
+75 +32 |
+92 +40 |
+112 +50 |
+134 +60 |
+159 +72 |
+185 +85 |
+215 +100 |
|||||||||
| D 10 | S |
+60 +20 |
+78 +30 |
+98 +40 |
+120 +50 |
+149 +65 |
+180 +80 |
+220 +100 |
+260 +120 |
+305 +145 |
+355 +170 |
|||||||||
| C 11 | S |
+120 +60 |
+145 +70 |
+170 +80 |
+205 +95 |
+240 +110 |
+280 +120 |
+290 +130 |
+330 +140 |
+340 +150 |
+390 +170 |
+400 +180 |
+450 +200 |
+460 +210 |
+480 +230 |
+530 +240 |
+550 +260 |
+570 +280 |
||
| wałek h11 |
0 -60 |
0 -75 |
0 -90 |
0 -110 |
0 -130 |
0 -160 |
0 -190 |
0 -220 |
0 -250 |
0 -290 |
||||||||||
| H 11 | S |
+60 0 |
+75 0 |
+90 0 |
+110 0 |
+130 0 |
+160 0 |
+190 0 |
+220 0 |
+250 0 |
+290 0 |
|||||||||
| D 11 | S |
+80 +20 |
+105 +30 |
+130 +40 |
+160 +50 |
+195 +65 |
+240 +80 |
+290 +100 |
+340 +120 |
+395 +145 |
+460 +170 |
|||||||||
| C 11 | S |
+120 +60 |
+145 +70 |
+170 +80 |
+205 +95 |
+240 +110 |
+280 +120 |
+290 +130 |
+330 +140 |
+340 +150 |
+390 +170 |
+400 +180 |
+450 +200 |
+460 +210 |
+480 +230 |
+530 +240 |
+550 +260 |
+570 +280 |
||
| A 11 | S |
+330 +270 |
+345 +270 |
+370 +280 |
+400 +290 |
+430 +300 |
+470 +310 |
+480 +320 |
+530 +340 |
+550 +360 |
+600 +380 |
+630 +410 |
+710 +460 |
+770 +520 |
+830 +580 |
+950 +660 |
+1030 +740 |
+1110 +820 |
||
* wg normy DIN 7157: S - pasowanie luźne
Psowania ISO - system otworu podstawowego (wg normy DIN 7154)
W systemie otworu podstawowego wszystkie otwory wykonywane są z tolerancją H. W ten sposób najmniejszy wymiar otworu dochodzi dokładnie do linii zerowej i jest równy wymiarowi nominalnemu. Największy wymiar wystaje o tolerancję ponad linię zerow.
  |
|
Wałki - pole tolerancji |
Rodzaj pasowania* | Wymiar nominalny ponad ......do ......mm | ||||||||||||||||||
|
1 3 |
3 6 |
6 10 |
10 14 |
14 18 |
18 24 |
24 30 |
30 40 |
40 50 |
50 65 |
65 80 |
80 100 |
100 120 |
120 140 |
140 160 |
160 180 |
180 200 |
200 225 |
225 250 |
||
| Odchyłki w ?m | ||||||||||||||||||||
| otwór H6 |
+6 0 |
+9 0 |
+9 0 |
+11 0 |
+13 0 |
+16 0 |
+19 0 |
+22 0 |
+25 0 |
+29 0 |
||||||||||
| p 5 |
+10 +6 |
+17 +12 |
+21 +15 |
+26 +18 |
+31 +22 |
+37 +26 |
+45 +32 |
+52 +37 |
+61 +43 |
+70 +50 |
||||||||||
| n 5 |
+8 +4 |
+13 +18 |
+16 +10 |
+20 +12 |
+24 +15 |
+28 +17 |
+32 +20 |
+38 +23 |
+45 +27 |
+51 +31 |
||||||||||
| k 6 |
+6 0 |
+9 -1 |
+10 +1 |
+12 +1 |
+15 +2 |
+18 +2 |
+21 +2 |
+25 +3 |
+28 +3 |
+33 +4 |
||||||||||
| j 6 |
+4 -2 |
+6 -2 |
+7 -2 |
+8 -3 |
+9 -4 |
+11 -5 |
+12 -7 |
+13 -9 |
+14 -11 |
+16 -13 |
||||||||||
| h 5 |
0 -4 |
0 -5 |
0 -6 |
0 -8 |
0 -9 |
0 -11 |
0 -13 |
0 -15 |
0 -18 |
0 -20 |
||||||||||
| otwór H7 |
+10 0 |
+12 0 |
+15 0 |
+18 0 |
+21 0 |
+25 0 |
+30 0 |
+35 0 |
+40 0 |
+46 0 |
||||||||||
| s 6 | P |
+20 +14 |
+27 +19 |
+32 +23 |
+39 +28 |
+48 +35 |
+59 +43 |
+72 +35 |
+78 +59 |
+93 +71 |
+101 +79 |
+117 +92 |
+125 +100 |
+133 +108 |
+151 +122 |
+159 +130 |
+169 +140 |
|||
| r 6 | P |
+16 +10 |
+23 +25 |
+28 +19 |
+34 +23 |
+41 +28 |
+50 +34 |
+60 +41 |
+62 +43 |
+73 +51 |
+76 +54 |
+88 +63 |
+90 +65 |
+93 +68 |
+106 +77 |
+109 +80 |
+113 +84 |
|||
| n 6 | U |
+10 +4 |
+16 +8 |
+19 +10 |
+23 +12 |
+28 +15 |
+33 +17 |
+39 +20 |
+45 +23 |
+52 +27 |
+60 +31 |
|||||||||
| m 6 |
+8 +2 |
+12 +14 |
+15 +6 |
+18 +7 |
+21 +8 |
+25 +9 |
+30 +11 |
+35 +13 |
+40 +15 |
+46 +17 |
||||||||||
| k 6 | U |
+6 0 |
+9 -1 |
+10 +1 |
+12 +1 |
+15 +2 |
+18 +2 |
+21 +2 |
+25 +3 |
+28 +3 |
+33 +4 |
|||||||||
|
j 6 |
U |
+4 -2 |
+6 -2 |
+7 -2 |
+8 -3 |
+9 -4 |
+11 -5 |
+12 -7 |
+13 -9 |
+14 -11 |
+16 -13 |
|||||||||
| h 6 | S |
0 -6 |
0 -8 |
0 -9 |
0 -11 |
0 -13 |
0 -16 |
0 -19 |
0 -22 |
0 -25 |
0 -29 |
|||||||||
| g 6 | S |
-2 -8 |
-4 -12 |
-5 -14 |
-6 -17 |
-7 -20 |
-9 -25 |
-10 -29 |
-12 -34 |
-14 -39 |
-15 -44 |
|||||||||
| f 7 | S |
-6 -16 |
-10 -22 |
-13 -28 |
-16 -34 |
-20 -41 |
-25 -50 |
-30 -60 |
-36 -71 |
-43 -83 |
-50 -96 |
|||||||||
| otwór H8 |
+14 0 |
+18 0 |
+22 0 |
+27 0 |
+33 0 |
+39 0 |
+46 0 |
+54 0 |
+63 0 |
+72 0 |
||||||||||
| x 8 | P |
+34 +20 |
+46 +28 |
+56 +34 |
+67 +40 |
+72 +45 |
+87 +54 |
+97 +64 |
+119 +80 |
+136 +97 |
+168 +122 |
+192 +146 |
+232 +178 |
+264 +210 |
+311 +248 |
+343 +280 |
+373 +310 |
+422 +350 |
+457 +385 |
+497 +425 |
| u 8 | P |
- - |
- - |
- - |
- - |
- - |
- - |
+81 +48 |
+99 +60 |
+109 +70 |
+133 +87 |
+148 +102 |
+178 +124 |
+198 +144 |
+233 +170 |
+253 +190 |
+273 +210 |
+308 +236 |
+330 +258 |
+356 +284 |
| h 6 | S |
0 -25 |
0 -30 |
0 -36 |
0 -43 |
0 -52 |
0 -62 |
0 -74 |
0 -87 |
0 -100 |
0 -115 |
|||||||||
| f 7 | S |
-6 -16 |
-10 -22 |
-13 -28 |
-16 -34 |
-20 -41 |
-25 -50 |
-30 -60 |
-36 -71 |
-43 -83 |
-50 -96 |
|||||||||
| d 9 | S |
-20 -45 |
-30 -60 |
-40 -76 |
-50 -93 |
-65 -117 |
-80 -142 |
-100 -174 |
-120 -207 |
-145 -245 |
-170 -285 |
|||||||||
| otwór H11 |
+60 0 |
+75 0 |
+90 0 |
+110 0 |
+130 0 |
+160 0 |
+190 0 |
+220 0 |
+250 0 |
+290 0 |
||||||||||
| h 9 | S |
0 -25 |
0 -30 |
0 -36 |
0 -43 |
0 -52 |
0 -62 |
0 -74 |
0 -87 |
0 -100 |
0 -115 |
|||||||||
| h 11 | S |
0 -60 |
0 -75 |
0 -90 |
0 -110 |
0 -130 |
0 -160 |
0 -190 |
0 -220 |
0 -250 |
0 -290 |
|||||||||
| d 9 | S |
-20 -45 |
-30 -60 |
-40 -76 |
-50 -93 |
-65 -117 |
-80 -142 |
-100 -174 |
-120 -207 |
-145 -245 |
-170 -285 |
|||||||||
| c 11 | S |
-270 -330 |
-270 -345 |
-280 -370 |
-290 -400 |
-300 -430 |
-310 -470 |
-320 -480 |
-340 -530 |
-360 -550 |
-380 -600 |
-410 -630 |
-460 -710 |
-520 -770 |
-580 -830 |
-660 -950 |
-740 -1030 |
-870 -1100 |
||
* wg DIN 7157: P - pasowanie wtłaczane, S - pasowanie luźne, U - pasowanie przejściowe
